Analysis with SystemModeler

Unlimited Analysis

Perform your own symbolic and numerical computations by accessing the full model equations and simulation results of your models. Bring the full power of the Wolfram Language to your model analysis.More

Programmatically control SystemModeler simulations and use built-in functions for finding model equilibria, linearizing models and more. Perform model calibration and system optimization using Mathematica’s symbolic and numerical features, and present your results with advanced graphics and interactivity. The Wolfram Language environment is designed to make exploration and analysis as efficient as possible. Entering commands into the notebook environment automatically creates a record of your work that can be shared with colleagues or reused and improved for future analyses. Notebooks combine code, data, explanatory text, plots, graphics and interactive elements in a single platform-independent document format. Prebuilt notebook templates for frequency and sensitivity analyses, model calibrations and more makes it easy to get started right away.Less


Design & Optimization

Use the Wolfram Language to help plan the geometry of 3D mechanical systems, prototype equation-based custom components, and use built-in optimization routines to find the optimal parameters and inputs.More

Once the model is assembled in SystemModeler, use sliders and other interactive elements to tune your models using manual exploration.Less


Model Calibration

Explore the parameter space by running SystemModeler simulations from the Wolfram Language. More

Calibrate model parameters against real-world data, using the Wolfram Language’s optimization features, and programmatically insert them back into the model.Less


Frequency Analysis

Perform FFT analyses on output signals and use the result to design dampers and filters. Stimulate your models with any input signal to find resonance peaks. More

Automatically convert a model into a linear time-invariant system to further analyze the system.Less


Sensitivity Analysis

Simulate models while plotting the sensitivity bands of system variables with respect to specified parameters. Sensitivity band plotting is built in. More

Discover which parameters have the greatest effect on system behavior, enabling you to increase model robustness, reduce model complexity and design optimal experiments.Less


Control System Design

Design controllers for your systems. A full suite of control systems features is built into the Wolfram Language, including stability analysis, visualization and controller design. More

Automatically linearize models into standard state-space representations or as transfer functions. Built-in functions allow you to tune PID controllers and create linear–quadratic regulators and state estimators.Less


Reliability Analysis

Wolfram Language’s complete suite for reliability analysis, with functionality for reliability block diagrams, fault trees and importance measures, can be used with models. More

Components and models can be annotated with reliability distributions, allowing you to test model robustness to design criteria by formal statistical methods.Less


Automatically Generate Reports

Run simulation models under different conditions and configurations and automatically generate customized reports based on the simulation results. More

Export the results in common formats such as PDF, HTML and LaTeX. Publish as interactive reports on the Wolfram Cloud or through Mathematica notebooks, using manipulates, sliders, graphics and other Wolfram Language elements.Less
